01557

Universal Straight Connector up to 1kV

Universal Straight Connector up to 1kV
larger imageMove mouse over the image to magnify
  • Connector composed of an Aluminium alloy body with Aluminium alloy bolts
  • Suitable for Al and Cu conductors when used with resin joints
  • Designed to meet the requirements of BS4579 Part 1 and Part 3 and engineering recommendation C79
UST1    UST2
Dimensions (mm)
Cat No. Description L H W Application Tool Cable Size Range
(mm²)
Qty
UST95
UNIVERSAL STRAIGHT CONNECTOR
80
25
25
13mm Socket
35-95
UST185
UNIVERSAL STRAIGHT CONNECTOR
108
32
34
19mm Socket
35-185
UST300
UNIVERSAL STRAIGHT CONNECTOR
108
36
40
19mm Socket
70-300
