01561

Universal Straight Connector with Double Service Takeoff up to 1kV

Universal Straight Connector with Double Service Takeoff up to 1kV
larger imageMove mouse over the image to magnify
  • A range of connectors for incorporating one or two service take off connections onto LV mains cables
  • These connectors are composed of an Aluminium alloy body with Aluminium alloy bolts
  • Suitable for Al or Cu conductors when used with resin joints
  • Designed to meet the requirements of BS4579 Part 1 and Part 3 and engineering recommendation C79
  • Can be installed under live working conditions (following suitable procedures)
USTXX-SBD 1
USBXX-D 1
Dimensions (mm)
Cat No. Number of
Service Take Offs
L H W Application Tool Cable Size
Main (mm²)
Cable Size
Tap Off (mm²)
Qty
UST95-SBD
DOUBLE
104
33
25
13mm Socket
35-95
6-35
UST185-SBD
DOUBLE
132
39
34
19mm Socket
35-185
6-35
UST300-SBD
DOUBLE
132
43
40
19mm Socket
70-300
6-35
