Pre-insulated Pin Connectors

Pre-insulated Pin Connectors
larger imageMove mouse over the image to magnify
  • Electro tinned Copper to minimise corrosion
  • PVC insulation
  • Circular pin
L42
Dimensions (mm)
Cat No. Terminal Size Conductor Area
(mm²)
A B D F Max. Insulation
Diameter (mm)
Tool No. Qty
H2276-D25
No. 1 Red
0.5 to 1.5
21.0
1.6
9.5
10.3
3.3
#76B/1, #102/1
H2276-D100
No. 1 Red
0.5 to 1.5
21.0
1.6
9.5
10.3
3.3
#76B/1, #102/1
H2278-D25
No. 2 Blue
1.5 to 2.5
23.8
2.0
10.3
11.9
4.3
#76B/1, #102/1
H2278-D100
No. 2 Blue
1.5 to 2.5
23.8
2.0
10.3
11.9
4.3
#76B/1, #102/1
H2280-D25
No. 3 Yellow
2.5 to 6.0
27.5
2.8
11.9
13.5
6.1
#76B/1, #102/1
H2280-D100
No. 3 Yellow
2.5 to 6.0
27.5
2.8
11.9
13.5
6.1
#76B/1, #102/1
