MWTM - Medium Wall Heatshrink

MWTM - Medium Wall Heatshrink
larger imageMove mouse over the image to magnify
Raychem MWTM tubing is fast and easily installed, and has proven its long term reliability in harsh climatic con­ditions and polluted environments.

APPLICATIONS
  • Fast cost effective way to waterproof joints
  • Low voltage underground jointing and terminations
  • Sealing of lugs and glands
  • Resistant to chemicals, corrosion and decay
TECHNICAL DATA
  • Operating Temperature range -40°C to 120°C
  • Shrink ratio 3:1
  • Adhesive lined
  • UV resistant
  • Voltage class 1kV
  • Sealant lined
  • Halogen free
DATA SHEET
MWTM EPP 1835 EN 4-13
MWTM

A = as supplied, B = after heating
Inside Diameter D (mm) Wall Thickness W (mm)
Cat No. Application
Range Diameter
(mm)
Min A Max B Min A. Max B. Length L Qty
MWTM-10-3-1200-S
3.5-9.0
10
3
0.3
1.0
1200mm
MWTM-16-5-1200-S
5.5-14.5
16
5
0.3
1.4
1200mm
MWTM-16/5-A/U-4
5.5-14.5
16
5
0.3
1.4
40m
MWTM-25-8-1200-S
9.0-22.5
25
8
0.4
2.0
1200mm
MWTM-35-12-1200-S
13.0-31.5
35
12
0.4
2.0
1200mm
MWTM-35/12-A/U-4
13.0-31.5
35
12
0.4
2.0
30M Roll
MWTM-50-16-1200-S
18-45.0
50
16
0.5
2.0
1200mm
MWTM-63-19-1200-S
21.0-57.0
63
19
0.6
2.4
1200mm
MWTM-75-22-1200-S
24.0-68.0
75
22
0.6
2.7
1200mm
MWTM-85-25-1200-S
28-77.0
85
25
0.6
2.8
1200mm
MWTM-115-34-1200-S
37.0-104.0
115
34
0.7
3.1
1200mm
MWTM-95-29-1200-S
32.0-86.0
95
29
0.7
3.1
1200mm
MWTM-140-42-1500-S
46.0-126.0
140
42
0.7
3.1
1200mm
MWTM-160-50-1200-S
55.0-144.0
160
50
0.7
3.2
1200mm
