Bimetal Parallel Groove Clamps

(0)No Reviews yet

Description

The body is composed of hot forged aluminium with a bimetallic sheet.

The bolts are made from galvanised steel.

TNPGB1670/1 5.1-11.7 16-70 3.0-9.0 6-50 1 25 0.06

Quantity

CTNPGB1670/2 5.1-11.7 16-70 3.0-9.0 6-50 2 40 0.15

Quantity

TNPGB25150/1 6.3-15.7 25-150 4.1-12.5 10-95 1 28 0.1

Quantity

TNPGB25150/2 6.3-15.7 25-150 4.1-12.5 10-95 2 48 0.2

Quantity

TNPGB35185/2 7.5-17.5 35-185 7.5-17.5 35-185 2 63 0.3

Quantity

TNPGB35185/3 7.5-17.5 35-185 7.5-17.5 35-185 3 95 0.6

Quantity

TNPGB35300/3 7.5-22.5 35-300 7.5-20.0 35-300 3 105 0.6

Quantity


	Cat No.	Overall Ø (mm) Aluminium	Size (mm²) Aluminium	OverallØ (mm) Copper	Size (mm²) Copper	Number of Bolts	Length (mm)	Approx. Weight (kg)	Qty	Price
