CRSM-CT - Single Phase LV Branch Joints

(0)No Reviews yet

Description

Applications

Single phase branch joints for low voltage plastic cables
DSWS Wraparound technology with thermo-sensitive paint as visual guide
Range taking USB Mechanical connector (-M kits only)
Suitable for direct burial
Branch off clip BOCL (-M & MD kits only) provides greater reliability of seal between two cables
Temperature range -40°C to 120°C

Downloads

CRSM-ANC-M-UNI YES - 16-35 4-35 YES - -

Quantity

CRSM-CT1-M YES - 35-95 16-35 YES - -

Quantity

CRSM-CT2-M YES - 70-185 16-50 YES - -

Quantity

CRSM-CT3-M YES - 185-300 16-35 YES - -

Quantity

CRSM-CT1-MD - YES 25-95 16-35 YES - -

Quantity

CRSM-CT2-MD - YES 50-185 16-35 YES - -

Quantity

CRSM-UBR-185 YES - 185 70-185 YES - -

Quantity

CRSM-CT-1-150 - - 16-150 1.5-35 NO 50 150

Quantity

CRSM-CT-50-300 - - 50-300 35-120 NO 100 200

Quantity

CRSM-CT-50-500 - - 50-500 120-185 NO 150 250

Quantity

		No. of Tails		Conductor Size (mm²)
	Cat No.	Single	Double	Main	Tail	Mechanical Connector Included	Connector Length (mm)	Maximum Joint Length Opening (mm)	Qty	Price
