EZYCLAMP - Nylon Hose Clamp
Designed and manufactured by HCL to the highest quality. The Ezyclamp™ is a highly versatile Nylon Worm Drive Hose Clamp. It is 12.7mm wide and available in 5 sizes covering a diameter range of 25mm to 150mm).
Features
- No Metal Parts – Non-Corrosive, Non-Magnetic, Non-Conductive
- Made in the United Kingdom
- Safe to fit – no sharp edges
- Excellent resistance to Weathering & UV
- 8mm Hex Screw fastener
- No Specialised Tooling Required
- Minimal Leak Path – forms almost Perfect Circle
- Manufactured to DIN3017 Standard
- Smooth Underside
- Bevelled Edges Protect Hose
- Exclusive Housing Design
| Material Specifications | PA12 | |
| Design Life (for outdoor use) | 20 years | |
| Flammability | HB, UL94 | |
| Temperature Resistance | Min ⁰C | -40 |
| Max ⁰C | 120 | |
| Continuous Use Temperature (Max ⁰C) | 100 | |
| Installation Temperature | Min ⁰C | -30 |
| Max ⁰C | 60 | |
| Minimum Tensile Strength, kg (N) | 160 (1570) | |
| Continuous Load, kg (N) | 9.1 (89) | |
DIMENSIONS
Cat No. | Min Dia (A) | Max Dia (A) | Band Width (B) | Band Thickness (C) | Screw Type | Max Torque | Qty | Price | ||
|---|---|---|---|---|---|---|---|---|---|---|
