MEASURING FUNCTIONS - Insulation measurements
- Diagnostic testing (PI, DAR, DD)
- Step voltage test
- Withstanding voltage test (DC) up to 5 kV
- Voltage and frequency measurement up to 550 V TRMS
APPLICATIONS - Power transformers
- Measuring transducers in distribution networks
- Testing insulation resistance of rotating machinery and cables
- Production line periodic testing and maintenance
- Troubleshooting and analysis of all kinds of insulation problems
- High voltage generators
- Surge arrestors and varistors
| KEY FEATURES - Insulation resistance up to 15 TΩ
- Adjustable test voltage (50 V...5 kV) 50 V and 100 V step
- Programmable timer
- Capacitance measurement
- Charging rate for capacitive load < 1.5 s / µF at 5 kV
- Automatic discharge of test object after completion of measurement
- Guard terminal
- High voltage breakdown detection
- Custom defined tests
- Auto adjustment function
- Measurement results in numerical and graphical form
- PC software HVLink PRO for downloading and analysing of the test results and test report printing
- Isolated RS232 and USB communication ports, BT interface
- High quality accessories including shielded test leads in standard set
- High EM interferences protection: Input AC current noise rejection (1 mA@300 V) and additional averaging of the result (5, 10, 30, 60)
- CAT IV / 600 V
- Increased working nominal altitude to 3000 m
- High power Li-ion battery pack (14.8V, 4.4Ah)
- Mains and rechargeable battery power supply
|
