HRC Fuse Link Cylindrical 22x58mm - ME Type (KR85)

HRC Fuse Link Cylindrical 22x58mm - ME Type (KR85)
larger imageMove mouse over the image to magnify
  • Rated Voltage: 500V AC
  • Rated breaking capacity: 100kA
  • Standard specifications: IEC EN 60269-2-1
  • Class: gG/gL
Fuse link cylindrical
Dimensions (mm)
Cat No. AMPS Pack Quantity A B C Qty
TNME5
5
5
58
22
9.5
TNME10
10
5
58
22
9.5
TNME20
20
5
58
22
9.5
TNME30
30
5
58
22
9.5
TNME40
40
5
58
22
9.5
TNME50
50
5
58
22
9.5
TNME60
60
5
58
22
9.5
TNME80
80
5
58
22
9.5
TNME100
100
5
58
22
9.5
