LED HAZARDOUS AREA BULKHEAD STANDARD AND EMERGENCY VARIANTS
The SPARTAN Bulkhead range is designed specifically for hazardous environments which require high performance, high reliability, White-Light illumination. Using Raytec’s field-proven, long-life LED technology, SPARTAN Bulkhead is ATEX and IEC Ex approved for all Zone 1 and Zone 2 applications and rated for T4 and T5 environments.
SPARTAN Bulkhead is ideal for applications where space is restricted with its compact, low profile design, which also allows easy access to the back of the unit with rear cable entries so cabling can be hidden and protected from damage. Housed in marine grade aluminium, SPARTAN Bulkhead is IP66 and IP67 rated and can survive the most extreme environments.
SPARTAN Bulkhead is available in a range of different beam patterns, both circular and elliptical, with revolutionary interchangeable VARIO lens inserts which can be easily altered on site delivering the ultimate flexibility to specifiers, distributors and end users.
Delivering high performance illumination of up to 2,500 lumens, SPARTAN Bulkhead is also available as an emergency fitting with integral battery back-up which can run up to 100% light output under emergency conditions.
ATEX and IEC Ex pending – Zone 1 and 2 (UL/CSA pending, including C1D2)
Ultra long life LED
High lumen output LED
Easy installation, maintenance and inspection
Wide operating temperature range of -50° to +46°C
VARIO lens technology – easy modification of beam patterns
Integral photocell (optional)
5 year warranty
Ultra-Powerful High lumen output - up to 2,500 lumens Latest high power LED technology
Ultra-Flexible Beam patterns from 10° to 120° both circular and elliptical. Operating temperature range of -50°C to + 46°C with a T4 and T5 rating for even the most challenging conditions. (-20°C emergency variants)
Models incorporating VARIO Technology allow for easy modification of beam pattern.
Industry leading 5 year warranty Designed and manufactured in the UK to the highest standards including both ISO9001 & ISO14001.
Advanced electronics and LED’s protected by vibration resistant and water proof potting compound
Both the LED and PSU modules are easily accessible for maintenance and inspection
Available as a standard or emergency fitting – upgradeable on site.
LEDs are thermally managed to deliver class leading energy efficiency Significant running and maintenance savings compared to traditional lighting technologies
SMART access wiring system for safe and efficient installation, set-up and ongoing inspection
Photometric files available (.ies & .ldt) Full Lighting Design Service Site specific Energy and Cost Saving Report available
For any model you don't see listed below, please contact us here as they will be available by special order.
For IES files relating to these products, please contact us
