The SPARTAN Mid-Power Bay range is designed to illuminate large, open spaces within hazardous area environments. Available with a range of different outputs from 5,000 to 15,000 lumens, the Mid-Power Bay uses Raytec’s field-proven, long-life LED technology to ensure a lifetime of 10 years+. All SPARTAN luminaires come with an industry-leading 5-year warranty.
BUILT POWERFUL - High lumen output from 5,000 to 15,000 lumens, along with a range of different beam patterns to effectively light up large open areas.
BUILT FLEXIBLE - The modular design allows easy access to key components and the ability to mount the PSU remotely, making installation and maintenance easy.
BUILT TOUGH - Constructed using tough, marine-grade aluminium and IP66 & IP67 rated, the MPBY is designed to withstand even the most challenging conditions.
ROBUST & DURABLE - Robust and durable construction from marine grade aluminium and with a wide operating temperature for even the most challenging conditions.
EASY TO MAINTAIN - Designed with maintenance in mind, featuring an innovative modular design to allow quick and easy on-site servicing.
SECONDARY OPTICS - Secondary optics are utilised to deliver a range of different beam patterns. This ensures light is targeted efficiently and there's no loss of light output on wider beam angle variants.
ATEX, UKEX and IEC Ex rated for Gas and Dust
Hazardous Area Rating
Zone 1 (Gas), Zone 21(Dust)
CML21ATEX3317 & IEC Ex CML21.0037 or CML21UKEX3319
II 2 G D, Ex eb mb IIC T4 Gb, Ta= -40°C to+60°C
Ex tb IIIC T90°C Db, Ta= -40°C to+60°C
110-277V 50/60Hz AC only
Incoming terminal block suitable for looping 4 core 4mm² cable
2xM20 as standard (other entries available upon request), dispatched complete with one ATEX/IEC Ex/UKEX approved blanking plug
Platinum Elite SMT LEDs
No. of LEDs
IP66 & IP67
-40°C to +60°C
Marine grade aluminium epoxy powder coated, toughened glass, all external fasteners and brackets are marine grade stainless steel
Silver (RAL 9006)
Ceiling brackets included
SPARTAN Mid Power Bay Light - Part Code Builder
W = White Light
Not Stated = 5700K
Not Stated = M20
4K = 4000K
