Support Units

TNHSP – Made from Aluminium Alloy and Neoprene inserts for AAC, AAAC & ACSR conductor

Support units offer superior protection to conductors (when compared with Line Guards and Armour Rods) from abrasion, compressive stresses and aeolian vibration.  Used in conjunction with clamp top insulators this unit fits directly into the trunion cap.

Consists of two neoprene cushioned halves, reinforced for enclosing the conductor within an Aluminium rod cage.  All this is secured by a two piece Aluminium housing.

Our Helical Support Units permit optimum tensioning of conductors with complete safety.  The neoprene supports grip the conductor gently, distributing clamping pressure over a greater area.  TNHSP units can accommodate line angles up to 30o.

Helical support units
Cat No. Conductor (mm) OD Colour AAC/AAAC ACSR Pack Quantity Qty
TNHSP1080
10.80
BLACK
-
MINK
20
TNHSP1125
11.25
BLACK
HELIUM
-
20
TNHSP1350
13.50
GREEN
HYDROGEN
-
20
TNHSP1430
14.30
BLUE
IODINE
DOG
15
TNHSP1625
16.25
ORANGE
KRYPTON
-
15
TNHSP1800
18.10
BLACK
-
WOLF
12
TNHSP1875
18.75
BLACK
NEON
-
10
TNHSP2100
21.00
RED
NITROGEN
COCKROACH
3
